HS-223 Lightweight Noise Protecting Headset

Great Acoustic Performance

Superb Ambient Noise Rejection

Boom Mic Switchable to Right Or Left Side

Rugged But Lightweight And Comfortable

Water Ingress Protection IP-X4

Built-in Loudspeaker output limiters

Share to

The HS-223 headset is designed for use in areas with high ambient noise levels, such as in motor sports, air & rail transport, and loud concert venues as it offers excellent wideband noise rejection and attenuation by both the microphone and earcups respectively.

Though it is rugged in construction, it is lightweight and offers superb wearing comfort even for long durations.  It also offers IP-X4 water protection.

Specifications

Microphone Style MH-12
Generating Element: Electret Condenser
Polar Pattern: Noise-Cancelling
Frequency Response: 300 Hz to 6 kHz
Sensitivity
(1 kHz @ ¼” distance)
2-wire:
-29 dB re 1 V/Pa (Nominal, 5V bias & 10 kOhm RL)
Bias Voltage: 2 Vdc to 12 Vdc
Impedance: 3k Ohm (typical)
Loudspeaker
Frequency Range: 300 Hz to10 kHz
Output: 90 dB SPL @ 1 mW 1kHz (Limited to 94 dB SPL max)
Impedance: 300 Ohm per side
(170 Ohm per side available)
General
Weight: 380 g
Cable Length: 1.2 m
Color: Black
Water Ingress Protection: IEC 60529 IP-X4
Standard Accessories: Windscreens, cable clip

Datasheet HS-223
